Diffuse mode sensor (สะท้อนวัตถุโดยตรง)
ระยะการตรวจจับ 1.2 เมตร
ใช้ได้ทั้งไฟ AC/DC 10 - 240 V , 5 สาย
Output Relay 1NO/1NC
สายยาว 2 เมตร

Operating voltage AC / DC
Highly visible LED
Relay output, 1 potential free alternator
Compact and stable housing
Protection class II

Detection range : 0 ... 1200 mm adjustable
Detection range max. : 0 ... 1200 mm
Reference target : standard white, 100 mm x 100 mm
Light source : LED
Light type : modulated visible red light , 630 nm
Polarization filter : no
Diameter of the light spot : approx. 25 mm at a distance of 1.2 m
Opening angle : 2 °
Ambient light limit : 50000 Lux ; according to EN 60947-5-2

Operation indicator : LED green: power on
Function indicator : LED yellow, lights up with receiver lit
Control elements : Sensing range adjuster
