-TeSys GV motor circuit breaker, 3 poles (3P), 10A/690V, for 3-phase motor applications 3-4kW@400V.
-magnetic protection with a tripping level at 13xIn,
-high breaking capacity Icu 100kA@400V.
-Connection by screw clamp terminals.
-Start-stop control by rotary handle guaranteed for 100 000 cycles AC-3.
-To complete motor protection, use in association with a thermal overload relay LRD14 (to be ordered separately).
-Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
